Surenoo Display Selection Guide for Graphic OLED Module

Model No.
SPU		 Content Outline Size
(MM)		 View Area
(MM)		 Active Area
(MM)		 Voltage Interface Mark Datasheet Controller Buy Now
(Image)
128X32 Dots Series
SOG12832A
-M223
18219009
 2.23"
128*32
Dots
 74.00*30.00
 57.00*15.10
 55.02*13.10
 3.3V
 7P: SPI/IIC
 7P/2.54
SSD1305
74.00*30.00
 57.00*15.10
 55.02*13.10
 3.3V 5P: IIC 5P/2.54
SOG12832B1
-M091
18361792
 0.91"
128*32
Dots		 32.50*20.50 24.38*7.58 22.38*5.58 3.3V 7P: SPI/IIC 7P/2.54 SSD1306
38.00*12.00 24.38*7.58 22.38*5.58 3.3V 4P: IIC 4P/2.54
 128X64 Dots Series
SOG12864A
-M270
20859921		 2.7"
128*64
Dots		 85.00*58.00 65.00*33.00 61.41*30.69 3.3-5.0V Parallel
SPI		 20P/2.54 SSD1325
SOG12864B1a
-M242
20980546		 2.42"
128*64
Dots		 72.00*42.80 57.00*29.50 55.01*27.49 3.3-5.0V IIC 5P/2.54 SSD1309
SOG12864B1b
-M242
20979673		 2.42"
128*64
Dots		 72.00*43.00 57.00*29.50  55.01*27.49 3.3-5.0V SPI/IIC 7P/2.54 SSD1309
SOG12864B1c
-M242
20979667		 2.42"
128*64
Dots		 70.50*49.60 57.00*29.50  55.01*27.49 3.3-5.0V Parallel/SPI/IIC 20P/2.54 SSD1309
SOG12864B2
-M242
20985504		 2.42"
128*64
Dots		 75.00*52.70 57.00*29.50
 55.01*27.49
 3.3-5.0V
 Parallel/SPI/IIC
 20P/2.54
4P/2.54
8P/1.0
 SSD1309
SOG12864C1
-M154
20991710
 1.54"
128*64
Dots		 58.00*32.00 37.05*19.52
 35.05*17.52 3.3-5.0V
 Parallel/SPI/IIC
 14P/2.54
 SSD1309
SOG12864C2
-M154
20991778		 1.54"
128*64
Dots		 42.40*38.00 37.05*19.52 35.05*17.52 3.3V 7P: SPI/IIC SSD1309
5P: IIC
SOG12856A
-TM151
22498427		 1.51"
128*56
Dots		 - 37.05*19.52 35.05*15.32 3.3V
3.3-5.0V		 SPI/IIC, IIC Transparent
OLED		 - SSD1309
SOG12864D
-M130
22560270		 1.30"
128*64
Dots		 35.40*33.50 31.42*16.70 29.42*14.70 3.3V 7P: SPI/IIC SH1106
4P: IIC
SOG12864E
-M096
22585543		 0.96"
128*64
Dots		 27.30*27.80 23.74*12.86 21.74*10.86 3.3V 7P: SPI/IIC SSD1306
4P: IIC
256X64 Dots Series
SOG25664A
-M550
19581632		 5.5"
256*64
Dots		 160.00*50.00 137.65*35.89 135.65*33.89
 3.3V 16P: Parallel/SPI 2*8P/2.54 SSD1322
160.00*50.00 137.65*35.89 135.65*33.89 3.3V 7P: SPI 7P/2.54
SOG25664B1
-M312
18361792		 3.12"
256*64
Dots		 100.50*33.50 78.78*21.18 76.78*19.18 3.3V Parallel
SPI		 2*8P/2.54
10P/1.0
7P/1.0
 SSD1322
SOG25664B2
-M312
19701002		 3.12"
256*64
Dots		 16P: 100.00*33.00 78.78*21.18 76.78*19.18 3.3V Parallel/SPI/IIC 2*8P/2.54
 SSD1362
 7P: 100.00*30.00 78.78*21.18 76.78*19.18 3.3V SPI/IIC  7P/2.54
 5P: 100.00*30.00 78.78*21.18 76.78*19.18 3.3V IIC 5P/2.54
SOG25664C
-M280
19745574		 2.8"
256*64
Dots		 97.00*32.50 71.10*19.26 69.10*17.26 3.3V Parallel
SPI		 2*8P/2.54 SSD1322
SOG25664D
-M208
19754399
 2.08"
256*64
Dots		 D1: 72.50*27.24 58.38*14.78 56.38*12.78 3.3V SPI/IIC  7P/2.54 SH1122
D2: 75.50*19.35 58.38*14.78 56.38*12.78 3.3V SPI 7P/2.54
Others Dots Series
SOG320132A
-M383
20218133		 3.83"
320*132
Dots		 124.00*42.00   90.90*38.07 89.90*37.07  3.3V  Serial SPI    SSD1320
SOG240128A
-M337
20351565
 3.37"
240*128
Dots
 102.00*59.20
 77.58*42.30 75.58*40.30 3.3V
 Parallel
Serial SPI
   SSD1306
SOG10016A
-M240
20501644		 2.4"
100*16
Dots		 80.00*36.00 66.00*16.00 59.95*11.15 3.3-5.0V  Parallel
Serial SPI		   WS0010
