SLC1602O PCB=80.00X36.00 1602 16*2 Surenoo Character LCD Module Display Screen Panel Serial IIC I2C AIP31068 Controller RGB LED Controller SN3193 FSTN Positive D-FSTN Negative with RGB LED Backlight for Arduino UNO Mega2560 Nano RaspBerry Pi
SLC1602O PCB=80.00X36.00 1602 16*2 Surenoo Character LCD Module Display Screen Panel Serial IIC I2C AIP31068 Controller RGB LED Controller SN3193 FSTN Positive D-FSTN Negative with RGB LED Backlight for Arduino UNO Mega2560 Nano RaspBerry Pi
Model No.: SLC1602O
Display Format: 16X02 Characters
PCB Size: 80.00X36.00MM
Controller: AIP31068 or Equal (RGB LED: SN3193)
Display Format: 16X02 Characters
PCB Size: 80.00X36.00MM
Controller: AIP31068 or Equal (RGB LED: SN3193)
100 sold
Quantity
Detail
Customer Reviews
- Important Note
- This Module can display any color of Characters / Backgound, but only one of the colors can be displayed at a specific point in time, the Characters / Backgound color is based on your code.
- SLC1602O_FNCIT: RGB Colors Dots on Black Background(Support 16 million Colors)
- SLC1602O_FPCIT: Black Colors Dots on RGB Background (Support 16 million Colors)
- SLC1602O V1.0: RGB LED Controller_PCA9633DP2 (Cost is very higher,off manufactrure already)
- SLC1602O V1.1: RGB LED Controller_SN3193 (Main Supply Part No.: SN3193)
- https://blog.csdn.net/zhenwenxian/article/details/8495356
- https://blog.csdn.net/zhenwenxian/article/details/8497495
- https://github.com/l740416/SN319351
- Surenoo 51 Library (1602_AI31068+SN3193_IIC)
- Overview
It's easily controlled by MCU such as 8051, PIC, AVR, ARM. It can be used in any embedded systems, industrial device, security, medical and hand-held equipment.
- Specification
| Gross Weight | 0.040Kg |
| Manufacturer | Surenoo |
| Display Type | Character LCD Module / IIC Display |
| Continuity Supply | More than 10 years |
| Part No. | SLC1602O V1.1 (RGB LED Controller: SN3193) |
| Display Format | 16x2 Character |
| Interface | Serial IIC |
| IC or Equivalent | LCD: AIP31068 or Equal / RGB LED: SN3193 or Equal (https://github.com/l740416/SN3193) |
| Fonts | English-Japanese |
| Voltage(Type) | 5.0V in default |
| Connection | 1X4P/2.0 PH2.0 Socket / 1X5P/2.54 Pin Header |
| Outline Dimension | 80.00(W)x36.00(H)x13.00(T)mm |
| Visual Area | 64.50x16.00mm |
| Active Area | 56.20x11.50mm |
| Display Type | FSTN Positive, D-FSTN Negative |
| Backlight Type | RGB LED |
| IC Package | COB |
| Viewing Direction | 6:00 O'Clock |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
- Outline Drawing
- Interface
| Pin No. |
Symbol |
Level |
Description |
|
| CN1 | CN2 | |||
| 1 | 1 | VSS | 0V | Ground |
| 2 | 2 | VDD | 3.3-5.0V | Logic Power Supply |
| 3 | V0 | - | Contrast Adjust | |
| 4 | 3 | SCL | H/L | Serial Clock Cable |
| 5 | 4 | SDA | H/L | Serial Data Cable |
- Documents
| No. | Item | File Name | File Type | ICON | Date | Description | Mark |
| 1 | Datasheet | SLC1602O |  |
2013-03-17 | Standard 1602 Character LCD Module | ||
| 2 | Controller | AIP31068 | |
2008-09-24 | AIP31068 Character LCD Controller, Build-in Serual SPI IIC | ||
| 3 | AIP31068 51 IIC Library | AIP31068 | C |  |
2017-08-22 | AIP31068 51 IIC Library on STC15W4K32S4 MCU | |
| 4 | Arduino IIC Library | IIC Library | HTML |  |
2024-03-19 | Surenoo IIC Library for PCT8574T RGB V2.0 to work on Arduino test Board |
