Model No.: SLC1602I
Display Format: 16X02 Characters
PCB Size: 66.70*37.46MM
Controller: ST7032s or Equal
11 sold
Quantity
ADD TO CART
BUY IT NOW
  • Detail
    • Overview
    SLC1602I is 16 characters wide, 2 rows character lcd module, ST7032 controller Integrated Serial SPI interface, wide operating temperature range, RoHS Compliant, built in character set supports English-Japanese, see the ST7032 datasheet for the full character set. It's 3.3V power supply, can connect with Arduino UNO to work directly.

    It's easily controlled by ARDUINO and Raspberry Pi. It can be used in any embedded systems, industrial device, security, medical and hand-held equipment.
    • Specification
    Gross Weight  0.020Kg
    Manufacturer Surenoo
    Display Type Character LCD Module
    Continuity Supply More than 10 years
    Part No. SLC1602I
    Display Format 16x2 Character
    Interface Integrated Serial SPI
    IC or Equivalent ST7032 or Equal
    Fonts English-Japanese
    Voltage(Type) 3.3V in default
    Connection I1: 1X10P/1.5 Iron Pin
    I2: 1X8P/2.54 Pin Header
    Outline Dimension I1: 41.50(W)x24.30(H)x3.90(T)mm
    I2: 41.50(W)x33.30(H)x4.90(T)mm
    Visual Area 37.60x13.80mm
    Active Area 34.21x8.76mm
    Display Type FSTN Positive
    Backlight Type (LED) White LED
    IC Package COG
    Viewing Direction 6:00 O'Clock
    Operating Temperature
    -20℃~70℃
    Storage Temperature
    -30℃~80℃
    • Outline Drawing
    1. SLC1602I1 Series

    2. SLC1602I2 Series

    • Interface
    Pin No. Symbol Description Pin No.
    		 Symbol
    		 Description
    SLC1602I1 (Without PCB Adapter) SLC1602I2 (With PCB Adapter)
    1 XV0S Bias Voltage (Insert 1uF Capacitor between them) 1 LEDA Power Suppy for Backlight (3.3V)
    2 V0S 2 VSS Ground 0V
    3 VGS Bias Voltage (Insert 1uF Capacitor between VGS and VDD) 3 VDD Logic Power Supply (3.3V)
    4 VDD Logic Power Supply (3.3V) 4 A0(RS)
    		 Register Selection Singal (H: Data Register; O: Command Register)
    5 VSS Ground 0V 5 RST Reset Pin
    6 D7(SDA) Serial Data Signal 6 CSB Chip Selelction
    7 D6(SCL) Serial Clcok Signal 7 SCK Serial Clock Signal
    8 CSB Chip Selection 8 SDA Serial Data Signal
    9 A0(RS) Register Selection Singal (H: Data Register; O: Command Register)
    10 RST Reset Pin
    BLA & BLK: 3.3V
    • Documents
    No. Item File Name File Type ICON Date Description Mark
    1 Datasheet SLC1602I PDF 2013-03-17 Standard 1602 Character LCD Module
    2 Controller ST7032 PDF 2008-09-24 Character LCD Controller: ST7032 support SPI Interface
    3 51 Library 51 Library C 2017-09-11 51 Library in SPI Interface
